- Part number: A181FM-0608-04
- Material: iglidur® A181
- Shape: Flanged bearings
- Dimensions:
- d1 6 mm
- d2 8 mm
- d3 12 mm
- b1 4 mm
- b2 1 mm
- Adjust dimension
- Manufacturing method: Injection moulding
- Service life:
- Universallagret för livsmedelskontakt
- Uppfyller EU-förordning 10/2011 EG
- Uppfyller FDA-kraven
- Universellt användbart
iglidur® A181 | The universal material for food contact
The iglidur® A181 material offers both FDA and 10/2011 EC conformity. The blue colour also facilitates the "optical detectability" frequently desired in the food sector. Directly comparable with iglidur® A180 in terms of mechanical specification, temperature and media resistance, iglidur® A181 is even better in terms of wear resistance in most constellations.
Typical application areas
- Beverage industry
- Food industry
- Medical technology
When do I use it?
- When FDA conformity is required
- When a material conforming to 10/2011 EC is required
- When a universal material for direct contact with food is required
When do I not use it?
- If FDA and 10/2011 EC conformity are not required
- If temperatures permanently higher than +90°C occur
- If a low-cost universal bearing is required
