- Part number: H370FM-0405-04
- Material: iglidur® H370
- Shape: Flanged bearings
- Dimensions:
- d1 4 mm
- d2 5.5 mm
- d3 9.5 mm
- b1 4 mm
- b2 0.75 mm
- Adjust dimension
- Manufacturing method: Injection moulding
- Service life:
- Lång livslängd under vatten och hög mediebeständighet.
- Nötningsbeständigt i synnerhet under vatten
- Hög temperaturbeständighet –40 °C till +200 °C
- Hög kemikaliebeständighet
iglidur® H370 | Highest service life under water and high media resistance
For applications under water, iglidur® H370 is the right solution. The material absorbs extremely high loads, is resistant to chemicals and can be used at temperatures up to +200°C.
Typical applications
- Fluid technology
- Offshore
- Shipbuilding
- Heavy machinery / Plant construction
- Packaging industry
When to use it?
- For use under water
- When high temperature resistance is required
- When high mechanical loading and wear resistance is required
- When good chemical resistance is required
When not to use it?
- When mechanical reworking of the wall surface is required
- When high wear resistance in temperatures is required
- For use in heavy dirt
- When a low-cost, high-volume solution is needed
